Spesifikasi Utama :
| Model (Standard Type) | Operation Position | Load Capacity (kg) | Load Center (mm) | Overall Width (Pallet Type 1.100/Pallet Type 1.200) – mm | Turning Radius (outside) – mm | Mast Lowered Height (mm) | Overall Length (mm) | Stacking Aisle Width (Pallet type 1.100/Pallet type 1.200) – mm | Main Aisle Width (Pallet type 1.100/Pallet 1.200) – mm |
|---|---|---|---|---|---|---|---|---|---|
| 8RFBA7 | Stand-Up | 700 | 550 | 1.450/1.550 | 1.580 | 2.695 | 2.570 | 1.480/1.580 00 | 2.930/3.030 |
| 8RFBA10 | Stand-Up | 1.000 | 550 | 1.450/1.550 | 1.750 | 2.795 | 2.750 | 1.580/1.680 | 3.100/3.190 |
| 8RFBA12 | Stand-Up | 1.200 | 550 | 1.550/1.650 | 1.750 | 2.795 | 2.750 | 1.580/1.680 | 3.080./3.170 |
| 8RFBA15 | Stand-Up | 1.500 | 550 | 1.550/1.650 | 1.910 | 3.045 | 2.900 | 1.580/1.680 | 3.260/3.350 |
Motor dan Elektrik Power :
| Model | Voltage Capacity | Electric Motors |
|---|---|---|
| 8RFBA7 | 48/370 V/Ah | Drive: 4.9 kW |
| 8RFBA10 | 48/445 V/Ah | Drive: 5.2 |
| 8RFBA10 | 48/445 V/Ah | Drive: 5.2 |
| 8RFBA12 | 48/445 V/Ah | Drive: 5.2 kW |
| 8RFBA15 | 48/445 V/Ah | Drive: 5.2 kW |
